Best Geotextile Fabric for Driveway
1. Super strong load-bearing and anti rolling: Adopting high-strength fiber structure, it can withstand long-term rolling and heavy load impact of vehicles, effectively resist deformation, and ensure the stability of lane structure.
2. Efficient drainage and water accumulation prevention: The unique permeable pore design can quickly discharge rainwater and surface water, avoiding the softening and settlement of the roadbed caused by water accumulation in the lane.
3. Durable and anti-aging: It has excellent UV resistance, acid and alkali resistance, is not easy to crack and rot in outdoor complex environment, and extends the service life of the lane.
4. Stabilize the roadbed and prevent collapse: By enhancing the friction between soil, suppressing the movement of roadbed soil particles, preventing potholes and collapses in the lane, and reducing maintenance costs in the later stage.
Products Introduction：
Best Geotextile Fabric for Driveway is a high-performance geosynthetic material designed specifically for lane construction and maintenance. It is made from high-quality polymer materials such as polypropylene and polyester fibers, processed through precise weaving or needle punching techniques, and has the characteristics of high strength and toughness. As a key reinforcement and protection material for lane structures, its core function is to enhance the stability of the lane base, prevent soil particle migration, and improve drainage performance, thereby effectively extending the service life of the lane and reducing the frequency of later maintenance. It is an ideal choice for improving engineering quality in residential and commercial lane paving.
Product Features：
1. Super strong load-bearing and anti rolling ability: Adopting a high-strength fiber interwoven structure, the tensile strength and tear strength far exceed ordinary geotechnical materials, and can easily withstand long-term rolling and dynamic load impact of vehicles (including heavy-duty trucks, SUVs, etc.). Even in frequent traffic scenarios, it can maintain structural integrity, avoid problems such as lane depression and cracking caused by excessive force, and provide solid structural support for the lane.
2. Efficient drainage and anti clogging performance: It has a uniform and stable pore structure, which can quickly discharge rainwater and accumulated water on the surface of the lane, prevent moisture from infiltrating the base layer and causing soil softening, and accurately block fine particles such as soil and sand, avoiding pore blockage and affecting drainage function. This feature can effectively reduce diseases such as lane frost heave and frost heave caused by water accumulation, and maintain the dryness and stability of the lane base.
3. Excellent weather resistance and durability: after special anti-aging treatment, the material has strong resistance to ultraviolet rays, temperature changes, acid and alkali erosion, etc. When exposed to outdoor sunlight, rain, snow, humidity, and other environments for a long time, it is not easy to experience problems such as brittleness, decay, and decreased strength. Its service life can reach 15-20 years or more, greatly reducing the maintenance and replacement costs of the lane.
4. Convenient construction and wide adaptability: The product is lightweight and flexible, and can be flexibly cut and spliced according to the shape of the lane (such as straight lines, bends, slopes, etc.), without the need for complex construction equipment. When laying, it can closely adhere to the base soil, adapt to different geological conditions (such as clay, sand, gravel soil, etc.), have high construction efficiency, and significantly shorten the construction period of the lane.
Product Parameters：
project | metric | ||||||||||
Nominal strength/(kN/m) | |||||||||||
6 | 9 | 12 | 18 | 24 | 30 | 36 | 48 | 54 | |||
1 | Longitudinal and transverse tensile strength / (kN/m) ≥ | 6 | 9 | 12 | 18 | 24 | 30 | 36 | 48 | 54 | |
2 | Maximum elongation at maximum load in longitudinal and transverse directions/% | 30~80 | |||||||||
3 | CBR top penetration strength /kN ≥ | 0.9 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 | |
4 | Longitudinal and transverse tearing strength /kN | 0.15 | 0.22 | 0.29 | 0.43 | 0.57 | 0.71 | 0.83 | 1.1 | 1.25 | |
5 | Equivalent aperture O.90(O95)/mm | 0.05~0.30 | |||||||||
6 | Vertical permeability coefficient/(cm/s) | K× (10-¹~10-), where K=1.0~9.9 | |||||||||
7 | Width deviation rate /% ≥ | -0.5 | |||||||||
8 | Unit area mass deviation rate /% ≥ | -5 | |||||||||
9 | Thickness deviation rate /% ≥ | -10 | |||||||||
10 | Thickness coefficient of variation (CV)/% ≤ | 10 | |||||||||
11 | Dynamic perforation | Puncture hole diameter/mm ≤ | 37 | 33 | 27 | 20 | 17 | 14 | 11 | 9 | 7 |
12 | Longitudinal and transverse fracture strength (grab method)/kN ≥ | 0.3 | 0.5 | 0.7 | 1.1 | 1.4 | 1.9 | 2.4 | 3 | 3.5 | |
13 | Ultraviolet resistance (Xenon arc lamp method) | Longitudinal and transverse strength retention rate% ≥ | 70 | ||||||||
14 | Ultraviolet resistance (fluorescence UV lamp method) | Longitudinal and transverse strength retention rate% ≥ | 80 | ||||||||
Product Applications：
1. Installation of family lanes: placed between the base and surface layers to enhance load-bearing capacity, prevent settlement and cracking caused by vehicle crushing, and accelerate rainwater drainage.
2. Construction of commercial parking lots: bear a large number of frequent vehicle traffic loads, reduce ground damage, extend the service life of parking lots, and reduce maintenance impacts.
3. Rural road renovation: As a grassroots reinforcement material, it improves the bearing capacity of low-grade roads and adapts to the traffic needs of agricultural vehicles and small trucks.
4. Temporary passage construction: used for construction sites, competition venues, etc., to quickly form temporary access roads, prevent vehicles from sinking into mud, and ensure smooth passage.
5. Slope lane protection: Lay according to the slope terrain, enhance soil friction, and prevent base slip and soil erosion caused by the slope of the lane.
Best Geotextile Fabric for Driveway has become a core material for improving quality and extending service life in lane construction due to its strong load-bearing and anti rolling performance, efficient drainage and anti clogging ability, excellent weather resistance and durability, and convenient construction characteristics. It can not only fundamentally solve the problem of lane damage caused by unstable grassroots and water erosion, but also bring significant economic benefits to residential and commercial scenarios by reducing maintenance costs and shortening construction periods. Whether it is building a new lane or renovating an old lane, this product can provide reliable structural support and protection, making it an ideal choice for creating durable, economical, and practical lanes.
